Avalue Technology - Industrial Computer

Processor

12th Generation Alder Lake Intel® Core™ i3-1215U Processor
(10M Cache, up to 4.40 GHz, with IPU)
12th Generation Alder Lake Intel® Core™ i5-1235U Processor
(12M Cache, up to 4.40 GHz, with IPU)

System Memory

2 x 262-pin DDR5 4800 MHz SO-DIMM Supports Up to 64GB (Non ECC Only)

I/O Chipset

EC iTE IT5782VG

Watchdog Timer

H/W reset, 1sec. ~ 65535sec. and 1sec./step

H/W Status Monitor

CPU Temperature Monitoring
Voltage Monitoring
CPU Fan Speed Control

TPM

2.0

SBC

EMX-ADLP-B1 A1 i3-1215U
EMX-ADLP-B1 A1 i5-1235U

Expansion

1 x M.2 Key B 3042/3052 for 4G/5G
1 x M.2 Key E 2230 support WiFi module
802.11abgn+acR2+axR2 Wi-Fi 6E BT5.2

Solid State Drive

2.5" SATA3 SSD

Other Storage Device

1 x M.2 Key M 2280 (PCI-e x4) slot for storage

Audio Codec

RealTek ALC888S-VD2-G

Speaker Output

2 x 2W

DC Input

+12V~+24V

DC Input Connector

Lockable PWR DIN Plug

Power Mode

ATX / AT

OS

Win11 / Linux

Certification Information

CE/ FCC class B/VCCI/UKCA

LCD Size

23.8"

Display Type

Full HD

Resolution

1920 x 1080

Pixel pitch

274.5mm × 274.5mm

Luminance

250 cd/m²

Contrast ratio

3000

Viewing angle

89(U), 89(D), 89(L), 89(R)

Response time

16ms

Backlight

LED

Touch Type

Projective capacitive multi-touch up to 10 points

Touch Controller

EETI EXC81H5680

USB Port

2 x USB 3.2 Gen2 (USB1)
2 x USB 3.0 Gen2 (USB2)

LAN Port

1 x Intel® I219LM Gigabit Ethernet PHY
1 x Intel® I226LM Gigabit Ethernet

Wireless LAN Antenna

2 x PCB Antenna

Display Port

2 x DP++

WLAN

Optional Wi-Fi + Bluetooth 5.0 USB Module, Intel Wi-Fi 6E AX210

Bluetooth

Optional Wi-Fi + Bluetooth 5.0 USB Module, Intel Wi-Fi 6E AX210

Operating Temp.

0°C ~ 40°C (32°F ~ 104°F)

Storage Temp.

-10°C ~ 60°C (14°F ~ 140°F)

Operating Humidity

40°C @ 95% Relative Humidity, Non-condensing

Dimension (W x L x H)

592 x 382 x 49.5mm

Weight

6.2 kg

Vibration Test

1.5Grms, IEC 60068-2-64, random, 5 ~ 500Hz, 30min/axis

Shock Test

10Grms, IEC 60068-2-27, half sine, 11ms

IP Rating

Front IP65

Mounting Kit

VESA 75 x 75, 100 x 100

System Fan

Fanless

Construction - Front

Plastic- black

Construction - Rear

Plastic- black

Adapter

AC/DC adapter 24V/3.75A PWR DIN Plug

Ordering Information

APC-2340-121-A1R
23.8" 1920x1080 Projected Capacitive Touch Panel PC (Plastics, Black)
Intel Core i3-1215U/8GB memory/ 4USB3/ 2LAN/ 2DP/ SPK/ 90W Adapter

APC-2340-123-A1R
23.8" 1920x1080 Projected Capacitive Touch Panel PC (Plastics, Black)
Intel Core i5-1235U/8GB memory/ 4USB3/ 2LAN/ 2DP/ SPK/ 90W Adapter

E971XAP2340001R
WiFi Kit for APC-2340

E971XAP2340002R
Camera Kit for APC-2340

E971XAP2340003R
NFC Kit for APC-2340

E170203183DR
EU Power Cord

E1702031835R
US Power Cord

E17120318001R
JP Power Cord

E170P060370R
UK Power Cord
