Processor

Rockchip RK3576S Quad core cortex A53+Quad core cortex A72

System Memory

Onboard 4GB RAM

Storage

Onboard 64GB eMMC

Other Storage Device

08/10WL : 1 x Mirco SD Card Slot (Support up to 128GB)

Graphic Chipset

Mali-G52 MC3 GPU

Audio Interface

08/10WL: Standard Single microphone
15WL: Standard Quad Microphone , Support noise reduction and echo cancellation

Speaker Output

08WL : 2 x 8Ω/2W
10WL : 2 x 4Ω/2W
15WL : 2 x 4Ω/3W

Ethernet Interface

10/100/1000 Base-Tx GbE compatible

DC Input

+12V
15WL : support Powered LAN IEEE 802.3at

DC Input Connector

DC Jack

Adapter

08/10WL : Input: 100 ~ 240Vac/ 50 ~ 60Hz​, Output: 18W (12V@1.5A) AC-DC adapter
15WL : Input: 100 ~ 240Vac/ 50 ~ 60Hz​, Output: 24W (12V@2A) AC-DC adapter

OS

08/10WL : Android 14
15WL : Android 15

LCD Size

08WL : 8"
10WL : 10.1"
15WL : 15.6"

Resolution

08/10WL : 800 x 1280
15WL : 1080 x 1920

Luminance

250 cd/m2

Contrast ratio

08WL : 1,200
10WL : 800
15WL : 1,000

Viewing angle

08WL : 80/80/80/80 (L/R/U/D)
10/15WL : 85/85/85/85 (L/R/U/D)

Backlight

3,000h

Touch Type

Projective capacitive multi-touch up to 10 points

USB Port

1 x USB 3.0
1 x USB Type-C (Only support OTG/ADB)
08 / 10WL : 1 x USB 2.0 (TTL)
15WL : 1 x USB 2.0 (Host)

Audio Port

08/10WL : 1 x Earphone

LAN Port

1 x RJ45

Other

15WL : Safety Lcok Hole

Control Buttons

Power

NFC

Optional NXP PN7160

Camera

5.0MP

WLAN

Optional Wi-Fi 802.11b/g/n/a/ac/ax

Bluetooth

Optional BT 5.4

Operating Temp.

0°C ~ 40°C (32°F ~ 104°F)

Storage Temp.

-20°C ~ 60°C (-4°F ~ 140°F)

Operating Humidity

20~80%RH

Dimension (W x L x H)

08WT : 211.8 x 104 x 132 mm
10WT : 255.5 x 114 x 160 mm
15WT : 365 x 173.9 x 220 mm

Weight

08WT : 0.79kg
10WT : 0.75kg
15WT : 2.52kg

Power Mode

AT/ATX (AT is default)

Packing List

1 x RPC-08/10/15WL
1 x 12V/1.5A or 12V/2A Adapter
