Processor

Rockchip RK3568J Quad-core Cortex-A55 1.8GHz

System Memory

4GB LPDDR4

Board

3.5"

Expansion

1 x M.2 Key E (2230, USB 2.0, supports Wi-Fi Module)
1 x M.2 Key B (3042, SATA3 / USB 2.0, support SSD/LTE Module)

Storage

64GB eMMC
1 x Micro SD Card Slot

Multiple Display

Dual Display
HDMI + LVDS/MIPI
HDMI + eDP

Graphic Chipset

Mali-G52 support OpenGL ES 1.1/2.0/3.2, Vulkan 1.0/1.1, OpenCL 2.0

Spec. & Resolution

1 x HDMI Max. resolution 4096 x 2160 @60Hz
1 x LVDS Support resolution 800 x 480, 1024 x 768, 1280 x 800
1 x MIPI Support resolution 1024 x 768
1 x eDP Support resolution 1920 x 1080

Ethernet Interface

10/100/1000 Base-Tx GbE compatible

LAN Chipset

2 x Realtek RTL8211FDI

LAN Port

2 x RJ45

DC Input

+12V ~ +24V

DC Input Connector

Lockable DC Jack

OS

Android 13
Debian 11

Certification Information

CE, FCC Class B

GPIO

1 x 16-bit GPIO by pin wafer

SIM Slot

1 x Nano SIM

Other

1 x Reset

COM Port

1 x RS232/422/485 DB9
3 x RS232 by pin header
1 x RS232/422/485 by pin header

USB

1 x USB 3.0 Type A
1 x USB 3.0 Type A support OTG
2 x USB 2.0 by pin header

Internal I/O Connector

1 x Backlight
1 x Debug
1 x I2C
1 x Speaker
1 x Touch Button
1 x DCin by pin wafer

Communication

2 x CAN by pin header

Display

1 x LVDS/MIPI co-lay
1 x eDP

Operating Temp.

-40 ~ 85°C (-40 ~ 185°F)

Storage Temp.

-40 ~ 85°C (-40 ~ 185°F)

Dimension (L x W)

146 x 101 mm

Weight

0.16 kg

Operating Humidity

40°C @ 95% Relative humidity, Non-condensing

Power Requirement

DC +12 ~ +24V

Power Mode

AT

Drop Test

ISTA 2A, IEC-60068-2-32 Test:Ed

Vibration Test

IEC 60068-2-64, 1.5 ~ 3.0 Grm, random, 5 ~ 500Hz, 30mins/axis

Ordering Information

RSC-3568J-6W-A104R
