Processor

Intel Atom® x6413E Processor, 1.5M Cache, up to 3.00 GHz

System Memory

1 x 260-pin DDR4 3200 MHz SO-DIMM socket, supports up to 32GB max (in-bend ECC supported)

I/O Chipset

EC ITE IT5571

Watchdog Timer

H/W reset, 1sec. ~ 65535min. and 1sec. or 1min./step

H/W Status Monitor

Monitoring CPU & system temperature and voltage

TPM

Onboard NuvoTon NPCT754AABYX support TPM 2.0

SBC

ARC-EHL

CPU Cooler (Type)

Fanless heatsink

Other

7 x Knockouts for antenna mounting
*5 from rear cover + 2 from IET bracket

Expansion

1 x M.2 Key-B 2242/3042/3052 with SIM card slot
Support SATA3 (BOM option for USB or PCIe for LTE(4/5G))

1 x M.2 Key-E 2230
Support PCIe/USB Wi-Fi/BT module

1 x 80-pin IET interface

Storage

1 x 2.5 Drive bay (7mm HDD restricted)

Graphic Chipset

Intel® Elkhart Lake SoC integrated graphics
supports optional dual display

Spec. & Resolution

HDMI: Max. Resolution 4096x2160 @ 24Hz (optional by IET module)

Audio Codec

Realtek ALC888S

Speaker Output

2 x 2W

LAN Chipset

2 x Intel® I225-IT 2.5 Gigabit Ethernet

Ethernet Interface

10/100/1000/2.5G Base-Tx GbE compatible

DC Input

+12V ~ +24V

DC Input Connector

Lockable DC Jack (default)
Optional for phoenix connector

ACPI

Single power ATX support S0, S3, S4, S5 and ACPI 3.0 compliant

OS

Win10 / Win11 / Linux

Certification Information

CE / FCC Class B / VCCI

LCD Size

15", 4:3

Display Type

XGA

Resolution

1024 x 768

Pixel pitch

0.297mm(H) x 0.297mm(V)

Luminance

300 cd/m2

Contrast ratio

2000

Viewing angle

88 (U), 88 (D), 88 (L), 88 (R)

Response time

16 ms

Backlight

LED

Touch Type

Projective capacitive multi-touch up to 10 points

Touch Light Transmission

89%

Touch Controller

USB touch (ILITEK ILI2511，COF)

USB Port

4 x USB 3.0

LAN Port

2 x RJ-45

COM Port

1 x RS-232/422/485
1 x RS-232

SATA

1 x SATA III

LED Indicator

HDD LED, power LED

Operating Temp.

Wide temp.-20°C ~ 55°C (-4°F ~ 131°F)

Storage Temp.

Wide temp.-30°C ~ 70°C(-22°F ~ 158°F)

Operating Humidity

40°C @ 95% Relative humidity, non-condensing

Dimension (W x L x H)

350.51 x 274.51 x 56.5mm

Weight

3.7 Kg

Vibration Test

With SSD/M.2 SSD : 3Grms, IEC 60068-2-64, random, 5 ~ 500Hz, 30mins/axis

Shock Test

Operating with SSD/M.2 : MIL-STD-810G, method 516.6, procedure I, functional shock=20G

Drop Test

ISTA 2A, IEC-60068-2-32 Test:Ed

IP Rating

Front panel IP65
Back cover IP41

Mounting Kit

Wall / Stand / VESA 75mm x 75mm, 100mm x 100mm
Panel mount with mounting kits

Power Mode

AT/ATX (ATX is default)

System Fan

Fanless

Construction - Front

Die casting with cover lens

Construction - Rear

Black die casting

Adapter

Input: 100 ~ 240Vac/ 50 ~ 60Hz
Output: 72W adapter (19V @ 3.78A adapter) AC-DC adapter

Ordering Information

ARC-1535-X13-B1-1R
15 1024x768 Industrial Touch Panel PC, ErP Design, PCAP Multi Touch(ALC888S)
Intel Atom SoC x6413E 1.50 GHz CPU/2GLAN/2COM/4USB/SPK/12~24V input/12V Adapter

Optional IET Module list:

ACC-ARC-USB-01R
4 x USB 3.0 IET module for ARC-1535/38

ACC-ARC-AUDIO-01R
HDMI + 5.1 CH audio IET module for ARC-1535/38

ACC-ARC-MPCIE-02R
HDMI + MPCIE w/SIM IET module for ARC-1535/38

ACC-ARC-COM-01R
2 x Isolated RS-232 IET module for ARC-1535/38

ACC-ARC-COM-02R
3 x RS-232 IET module for ARC-1535/38

ACC-ARC-COM-03R
2 x RS-232 + USB IET module for ARC-1535/38

ACC-ARC-COM-04R
2 x RS-232 + LAN IET module for ARC-1535/38

ACC-ARC-GPIO-01R
12-bit GPIO + 2-pin CAN bus IET module for ARC-1535/38

ACC-ARC-OBDII-01R
OBDII - CAN bus IET module for ARC-1535/38 (OBDII/EOBD for small vehicle)

ACC-ARC-OBDII-02R
OBDII - CAN bus IET module for ARC-1535/38 (J1939J1708 for large vehicle)

ACC-ARC-OBDII-03R
OBDII - CAN bus IET module for ARC-1535/38 (ISO15765-4 for special large vehicle)

E1702031835R
USA Power Cord

E170203183DR
EU Power Cord

E170203183BR
Japan Power Cord

E170P060370R
UK Power Cord

E170P060392R
Australia Power Cord
