AVAILABLE
VNS-15W01
15.6 Venus Panel PC
_V01_200709.png)
_V01_200709.png)
_V01_200709.png)
- Intel Atom® x5-Z8350 Processor
- 2GB/ 4GB DDR
- 32GB/ 64G eMMC
- CE, FCC Class B
产品规格
System Information
-
Processor
Intel Atom® x5-Z8350 Processor
-
Platform Controller Hub
Intel x5-Z8350
-
System Memory
2GB / 4GB DDR3L
Storage
-
Storage
32GB/ 64GB eMMC
Display
-
Spec. & Resolution
LVDS: Max. resolution 1920x1280 @ 60Hz
-
Multiple Display
Windows support extended mode
Audio
-
Speaker Output
4Ω 2.0W/2.5W(MAX)
Ethernet
-
LAN Chipset
Realtek RTL8111H(S)-CG
Power Requirement
-
DC Input
12~24V
Software Support
-
OS
Windows 10 IoT (64 bit), Android 5.1(64 bit), Linux (64bit)
Certification
-
Certification Information
CE/FCC Class B
Panel
-
LCD Size
15.6"
-
Resolution
1920x1080
-
Luminance
220 cd/m2
-
Viewing angle
89 (U), 89 (D), 89(L), 89 (R)
-
Touch Type
PCAP
External I/O
-
LAN Port
1 x RJ-45
Internal I/O
-
External I/O Connector
1 x 10/100/1000 RJ45 Powered LAN
2 x USB 2.0 Type A
1 x Headphone Jack -
Internal I/O Connector
1 x A-MIC
1 x eDP
1 x I2C
2 x LED Bar
1 x Micro SD slot
1 x Micro USB
1 x Touch Button
5 x USB
Data Collection
-
NFC
NFC Reader
Data Communication
-
WLAN
WIFI 802.11 b/g/n
Mechanical & Environmental
-
Operating Temp.
0°C ~ 40°C (32°F ~ 104°F)
-
Storage Temp.
-10°C ~ 60°C(-14°F ~ 140°F)
-
Operating Humidity
40°C @ 95% Relative Humidity, non-condensing
-
Weight
2.5 kg
-
VESA
75 x 75
-
Dimension (W x L x D)
472.1 x 269 x 70.1 mm
-
Power Requirement
DC 12~24V
-
Power Mode
DC jack or Powered LAN 802.3AT
Ordering Information
-
Ordering Information
VNS-15W01-BV37C-1R : VNS-15W01-32G-Ubuntu 19.04 (抗)
VNS-15W01-BV38C-1R : VNS-15W01-32G-2016 Win 10 (抗)
VNS-15W01-BV38C-3R : VNS-15W01-32G-2019 Win 10 (抗)
VNS-15W01-BV39C-1R : VNS-15W01-32G-Android 5.1 (抗)
VNS-15W01-BW47C-1R : VNS-15W01-64G-Ubuntu 19.04 (抗)
VNS-15W01-BW48C-1R : VNS-15W01-64G-2016 Win 10 (抗)
VNS-15W01-BW48C-3R : VNS-15W01-64G-2019 Win 10 (抗)
VNS-15W01-BW48C-5R : VNS-15W01-64G-2016 Win 10 (抗 / AID HS)"
