Processor

LGA 1700 Socket Supports 12/13/14th Generation Intel® Core™ i9/i7/i5/i3 Processors (Max. TDP at 65W)

Platform Controller Hub

Intel® H610 chipsets

System Memory

2 x 288-Pin DDR4 3200MHz U-DIMM Socket Supports Up to 64GB

I/O Chipset

ITE IT8786E-I

Watchdog Timer

H/W Reset, 5~255 seconds/5~255 minutes

BIOS

AMI uEFI BIOS, 256Mbit SPI Flash ROM

H/W Status Monitor

CPU Temperature Monitoring
Voltage Monitoring
CPU Fan Speed Control

TPM

Onboard SLB9670 VQ20 supports TPM 2.0 (By BOM Optional)

Board

ATX

Expansion

1 x PCIe Gen4 x16 Slot
2 x PCIe Gen3 x2 signal by PCIex4 Slot
1 x PCIe Gen3 x4 Slot(Only support PCIe Gen3 x2)
3 x PCI Slot

Storage

1 x M.2 Key M Support 2280 SATA SSD
3 x SATA III

Graphic Chipset

Intel® 12th/13/14th Generation CPU Integrated

Spec. & Resolution

1 x HDMI 1.4b, max resolution up to 4096x2160@30Hz
1 x DVI-D, max resolution up to 1920x1200@60Hz
1 x VGA, max resolution up to 1920x1200@60Hz

Multiple Display

Triple Display

Audio Codec

Realtek ALC897 Audio codec

Audio Interface

Line-in, Line-out, Mic-in

LAN Chipset

1 x Intel® i226V 2.5 Gigabit Ethernet Controller, 1 x Intel® WGI219V Gigabit Ethernet Controller

LAN Port

2 x RJ-45

Power Mode

AT/ATX (Default Setting: ATX)

OS

Windows 11

Certification Information

CE, FCC, RoHS Compliant

USB

4 x USB3.2 Gen1x1, 2 x USB2.0, 1 x USB2.0 Vertical Type A, 3 x USB2.0 by pin header

COM Port

1 x RS-232 at I/O
2 x RS-232/485 by Box header
3 x RS-232 by Box header

SATA

3 x SATA III

DIO

1 x 8-bit GPIO

MIO

1 x PS/2 Keyboard and Mouse

Operating Temp.

0~60°C (32~140°F)

Storage Temp.

-40~ +75°C (-40~167°F)

Operating Humidity

40°C @ 95% Relative Humidity, Non-condensing

Weight

1.54lbs (0.7kg)

Power Requirement

+12V/+5V/5VSB/+3.3V/-12V

Power Mode

AT/ATX (Default Setting: ATX)

Dimension (L x W)

12" x 9.6" (304.8mm x 243.84mm)
