COMING SOON
AIB-3588AI
AI Edge Computing
- Support 32 channels 1080P 30FPS, support 8K video editing and decoding.
- Supports LPDDR up to 32GB and EMMC up to 256GB.
- Supports HDMI® IN video input and USB camera combination.
- Support Dual HDMI® Output and DP Out
- Support USB3.0/USB2.0/GPIO/CAN/RS485/RS232/TTL peripheral interfaces.
- Support M.2/SATA3.0/ GTIOT/SPI/ I2C/UART/USB2.0 and other internal expansion
- Support Tringle Gigabit wired network
- Built-in watchdog and RTC battery can support 7*24 hours stable operation.
- Support multiple operating systems: Android13 & Debian11 & Ubuntu
- Support AI module build-in(Optional)
产品规格
System Information
-
Processor
Rockchip RK3588, Quad-core Cortex-A76 and Quad-core Cortex-A55
-
System Memory
4GB LPDDR4(8/16/32GB optional)
-
GPU
Mali-G610 MP4 (4x256KB L2 Cache)
-
AI accelerator
6TOPs NPU
Storage
-
eMMC
32GB EMMC(64GB/128GB/256GB optional)
I/O
-
Network
3x1000M Ethernet
External I/O Connector
-
External I/O Connector
USB3.0 x 2/USB2.0 x 2/HDMI® OUT x 2/HDMI® IN x 1/SIM Card Slot/TF Slot/DB9 x 2/RS-232 x 2/RS-485 x 2/CAN x 2/GPIO x 6/AC IN
Power Requirement
-
Power Requirement
AC 220V 50Hz
Software Support
-
OS
Android13 (first)
Mechanical & Environmental
-
Operating Temp.
Operation temperature: commercial (0°C~ +60℃)/ Extended commercial (-40 °C ~ 85°C)
-
Operating Humidity
0%≤Relative humidity≤90%
-
Dimension (W x L x H)
247 mm * 230 mm *55mm
