System Memory

2GB LPDDR4

Processor

Quad-core Cortex-A55

Chipset

Rockchip RK3568J

Storage

16GB eMMC 5.1

PCIe

1 x 3.0
1 x 2.0

GPIO

x 24

LVDS

x 1 single channel (share with MIPI DSI)

HDMI

x 1 , 4k60Hz

I2C

x 3

eDP

x 1

MIPI CSI

x 1 (4 lane)

MIPI DSI

x 2 (4 lane) one share with LVDS

SPDIF

x 1

I2S

x 2

SPI

x 2

CAN

x 2

SDIO

2 x SDIO 3.0

COM

1 x debugging port
2 x UART

Network

2 x RJ45, 1000M

USB Port

1 x USB Host 3.0
1 x USB OTG 3.0
2 x USB Host 2.0

Certification Information

CE, FCC Class B

Storage Temperature

-40~95 Degree

Dimension

45mm x 45mm (Size-L)

Power Requirement

DC input voltage 5V

Operating Humidity

5% to 95%, non-condensing

Operating Temperature

Industry：-40~85 Degree

OS Information

Linux Debian 11 (First),
Android 11

Ordering Information

TBD

Gigabit Ethernet

RJ45 (100M/1000M Ethernet)x2

USB

2 x USB 3.0 Host, 2 x USB 2.0 Host, 1 x USB Type C(OTG)

Mini-PCIE

x 1

MIPI CSI

x 1

MIPI DSI

x 1

DC-IN

x 1

SW

K1 (Recovery mode)

Dimensions

125 x 120 mm

Display

Support HDMI x 1 /eDP x 1, MIPI DSI interface

CAN

x 2

SPI

x 1

UART

x 2

Adapter

DC input voltage 12V
