製品仕様
System Information
System Memory
32GM/64GB LPDDR5
Processor
Jetson AGX Orin 32GB /
Jetson AGX Orin 64GB
AI Performance
AI Performance
64GB:275 TOPS
32GB:200TOPS
Expansion
Expansion
1 x M.2 M Key (PCIe x 4, 2280)
1 x mPCIE (for 4G or WIFI expansion)
1 x Nano SIM Slot
Storage
Storage
64GB eMMC 5.1
Development Environment
OS
Linux
Certification
Certification Information
CE, FCC Class B
External I/O connector
USB
2 x USB3.0 (typeA)
COM
5 x CAN FD
8 x GPIO (4x In, 4xOut)
3 x RS232
2 x RS485/422
1 x Debug (RS232)
3 x SYNC I/O (SYNC_IN/SYNC_OUT/SYNC_PPS)
Network
4x10/100/1000 RJ45 Powered LAN
Display
1 x HDMI 2.0 (typeA)
Function key
1× Power KEY, 1× Reset KEY, 1× Recovery KEY
User Expansion
1 x mPCIE (for 4G or WIFI expansion)
1 × M.2 M Key (PCIe x 4, 2280)
1 x Nano SIM slot
Camera
2 x GMSL2 (4 in 1 mini PAKRA type, IOV, transmission distance up to 15 meters, GMSL2 compatible with GMSL1)
Mechanical & Environmental
Power Requirement
DC 9V~36V
Dimension (W x L x H)
276 ×214 ×71 mm (I/O ports and mounting holes included)
Operating Temp.
-25°C ~ 70°C (-13°F ~ 158°F)
Storage Temp.
-40°C ~ 80°C (-40°F ~ 176°F)
Ordering Information
Ordering Information
TBD
